AR-15 5.56/.223 Wylde 20" Stainless Steel Straight-Fluted Upper Assembly – 15" Moriarti M-LOK, Triport Brake

Brand:Moriarti Armaments
Product Code:MAR-556-20-STR-TRI
Availability:In Stock
star_border star_border star_border star_border star_border
mode_comment0 reviews editWrite a review
  • $299.95

  • $549.95

Available Options

20" 5.56 Upper: Specs & Features

The Moriarti AR-15 5.56/.223 Wylde 20" Stainless Steel Straight-Fluted Upper Assembly combines precision-oriented barrel construction with a modern free-floating handguard and durable forged upper receiver.

Built around a 20-inch 416 stainless steel HBAR barrel, this upper features straight fluting, a 1:8 twist rate, and button rifling. The barrel is hardened to 26–32 HRC and stress relieved for durability and consistent performance. Its .223 Wylde chamber accommodates both 5.56 NATO and .223 Remington ammunition.

A rifle-length gas system, .750-inch low-profile steel gas block, and rifle-length gas tube complete the gas configuration. The barrel features 1/2×28 muzzle threads and comes equipped with a Triport muzzle brake and crush washer.

The 15-inch Moriarti free-floating M-LOK handguard is manufactured from aircraft-quality aluminum with a black hardcoat anodized finish, providing a streamlined profile and versatile accessory mounting.

The assembly is completed with a forged 7075-T6 aluminum A3 flat-top upper receiver, black hardcoat anodized to government specifications, with an installed forward assist, dust cover, and M4 feed ramps.

Designed for compatible AR-15 platforms, this upper offers a combination of stainless steel barrel construction, practical modularity, and precision-focused performance.

Key Features

  • 20" 416 stainless steel HBAR barrel

  • Straight-fluted barrel design

  • .223 Wylde chamber compatible with 5.56 NATO and .223 Remington

  • 1:8 right-hand twist, button rifled

  • Barrel hardened to 26–32 HRC and stress relieved

  • M4 feed ramps

  • Rifle-length gas system and gas tube

  • .750" low-profile steel gas block

  • 1/2×28 threaded muzzle

  • Triport muzzle brake with crush washer

  • 15" Moriarti free-floating M-LOK handguard

  • Aircraft-quality aluminum handguard with black hardcoat anodized finish

  • Forged 7075-T6 A3 flat-top upper receiver

  • Black hardcoat anodized receiver

  • Installed forward assist and dust cover

Specifications

SpecificationDetails
ManufacturerMoriarti Armaments
PlatformAR-15
Caliber5.56 NATO / .223 Remington
Chamber.223 Wylde
Barrel Length20"
Barrel Material416 Stainless Steel
Barrel ProfileHeavy / HBAR
Barrel DesignStraight Fluted
Barrel Hardness26–32 HRC
Barrel TreatmentStress Relieved
RiflingButton Rifled
Twist Rate1:8 RH
Feed RampsM4
Gas SystemRifle-Length
Gas TubeRifle-Length
Gas Block.750" Low-Profile Steel
Muzzle Threads1/2×28
Muzzle DeviceTriport Muzzle Brake
Muzzle WasherCrush Washer
Handguard15" Moriarti Free-Floating M-LOK
Handguard MaterialAircraft-Quality Aluminum
Handguard FinishBlack Hardcoat Anodized
Upper ReceiverForged A3 Flat-Top
Receiver Material7075-T6 Aluminum
Receiver FinishBlack Hardcoat Anodized
Forward AssistInstalled
Dust CoverInstalled

Package Includes

  • Assembled AR-15 .223 Wylde 20" upper receiver assembly

  • Installed 20" stainless steel straight-fluted HBAR barrel

  • Installed Triport muzzle brake and crush washer

  • Installed rifle-length gas system

  • Installed 15" Moriarti free-floating M-LOK handguard

  • Forged A3 upper receiver with forward assist and dust cover

FAQ

Can this upper fire both 5.56 NATO and .223 Remington?

Yes. Its .223 Wylde chamber is designed to accommodate both 5.56 NATO and .223 Remington ammunition.

What is the advantage of a straight-fluted stainless steel barrel?

Straight fluting removes material from the heavy barrel profile, reducing weight compared with an otherwise equivalent unfluted barrel while retaining the benefits of stainless steel construction.

What gas system does this upper use?

It features a rifle-length gas system with a rifle-length gas tube and .750-inch low-profile steel gas block.

What muzzle device is included?

A Triport muzzle brake is installed using the barrel's 1/2×28 muzzle threads and a crush washer.

Is this upper compatible with standard AR-15 lowers?

It is designed for compatible mil-spec AR-15-pattern lower receivers.
